Hitachi M12V2 15 amp 3-1/4-Horsepower Plunge Base Variable Speed Plunge Router with 1/4-inch and 1/2-inch Collets

Sunday, April 15, 2012

Product Details

Product Dimensions: 11 x 9 x 12 inches
Shipping Weight: 21.2 pounds (View shipping rates and policies)
Shipping: Currently, item can be shipped only within the U.S. and to APO/FPO addresses. For APO/FPO shipments, please check with the manufacturer regarding warranty and support issues.
Shipping Advisory: This item must be shipped separately from other items in your order. Additional shipping charges will not apply.
ASIN: B000GKC28W
Item model number: M12V2

By : Hitachi
Price : $204.00
You Save : $193.78 (49%)

Product Description

Amazon.com Product Description
The Hitachi M12V2 3-1/4-Peak Horsepower Plunge Router features a powerful variable-speed motor with soft-start technology for handling smooth groove cutting, chamfering, window cutting, trimming, shaping, and pattern cutting in a variety of materials, including hardwoods. An updated version of Hitachi's popular M12V Router, the M12V2 offers many new features that enhance both usability and performance, making it an ideal tool for any woodworker or carpenter.

This easy-to-use router features a clearly marked depth scale and a handle-mounted speed dial.(Click squares to zoom in on components.)
M12V2 3-1/4-Peak Horsepower Plunge RouterTool Specifications
Full-Load Current
15 Amps
Power Input
2,000 Watts
Peak Horse Power
3-1/4 HP
No-Load Speed
8,000 - 22,000 RPM
Constant Speed Control
Yes
Soft Start
Yes
Plunge Stroke
2-9/16"
Brake
No
Switch Type
Slide
Soft Grip
Yes
Quick ; Fine Adjustments
Yes
Dust Guide
Yes
Speed Control Dial Position
Handle
Maximum Collet Capacity
1/2"
Tool Weight
13.9 lbs.Variable-Speed Motor with Integrated Soft-StartThe M12V2's powerful 15 Amp motor produces top-of-class cutting speed to rout through hardwoods with ease. The motor also features soft-start technology, producing 3/4 peak horsepower while reducing torque during startup.
Equipped with an electronic variable-speed dial, the M12V2 produces 8,000 to 22,000 RPM, so you can tackle a wide range of cutting applications in a wide range of materials. The variable-speed dial is conveniently located on the handle so you can finely adjust the rotation speed without taking your hands or eyes off your workpiece.
Easily Customizable Router Meets All Your NeedsThe M12V2 has many features that are customizable to your needs. To start, a unique quick and fine adjustment knob combines both functionalities into the same mechanism, so you can quickly and accurately dial the right plunge depths for the job.
Additionally, the router easily converts to table use for larger projects--the collet chuck protrudes 6mm from the upper side of the table for easy bit changes. For further flexibility on the job, 1/4-inch and 1/2-inch collets are included with the router. The collet chuck secures bits into the armature shaft for maximum hold during operation.
Ergonomically Designed for Comfort and ControlLike all Hitachi tools, the M12V2 is ergonomically designed to enhance comfort and control on the job. For beginners, this tool weighs only 13.9 pounds, making it safe and stable enough for freehand routing. Additionally, the handles are wrapped in Elastomer compound to reduce vibration and prevent slippage for ultimate control. For further ease of use, an included dust guide keeps dust and debris away from the cutting surface, so you get all the visibility you need to make clean, accurate cuts.
The M12V2 Plunge Router is backed by Hitachi's industry-leading five-year limited warranty.
About Hitachi: A Tradition of InnovationHitachi Power Tools (Hitachi Koki USA, Ltd.) provides professional-grade power tools for a variety of applications, including woodwork, metalwork, concrete, drilling, cutting, and fastening. Hitachi is a leader in power tool research and development and has achieved many firsts in the power tool industry, including creating the first-ever sliding compound miter saw to combine the capacity of a radial arm saw and the convenience of a miter saw. Today, Hitachi continues the tradition of innovation and engineering with new features in addition to classic quality.
What's in the BoxM12V2 Plunge Router, 1/2-inch collet, 1/4-inch collet, straight guide, centering gauge, dust adapter, guide bar, wing bolt, and wrench.
Includes: Straight Guide - 956797, Centering Gauge - 325233, Dust Adapter - 325215, Guide Bar - 325216, Wing Bolt - 301806, Wrench - 323293, 1/4" Collet - 323293, 1/2" Collet - 301795. Easily converts to table use. Bits can be easily changed from a table mounting as the collet chuck is designed to protrude 6mm from the upper side of the table. Equipped with an improved collet chuck that secures the bit into the armature shaft for maximum hold. Dust guide diverts dust and debris away from the work piece and user. Weighs 13.9 lbs making it safe and stable for freehand routing. Ergonomic design for enhanced comfort and control. Elastomer covers the handles to reduce transfer of vibration and prevent slippage. Amps: 15. Horsepower: 3-1/4 HP. No Load Speed: 8,000 - 22,000 RPM. Collet Diameter: 1/2", 1/4". Plunge Stroke: 2-9/16". Tool Weight: 13.9 lbs.
See all Product Description

Technical Details

Powerful 3-1/4 peak-horsepower variable speed plunge router
Variable speed dial produces 8,000 to 22,000 RPMs for a wide range of cutting options
Aluminum fan of armature; soft-grip handle
Includes router, straight guide, centering-gauge, dust adapter, guide bar, wing bolt, wrench, and collets (1/4 and 1/2-inch)
13.9-pounds; 5-year warranty

Hitachi M12V2 15 amp 3-1/4-Horsepower Plunge Base Variable Speed Plunge Router with 1/4-inch and 1/2-inch Collets

Customer Reviews

I bought this router as an upgrade from a crappy, underpowered Craftsman 1/4" router that I had for years. That thing was so bad that it turned me off from using routers, and I hardly touched it for years. It was underpowered, wouldn't hold a bit, and screamed like a banchee even under light cuts.
Now that I have this new M12V2 I love routing again! It's awesome.
High Points:
Power: This thing is powerful! I just ordered some panel raising bits and have no doubt this will drive those very well. I will try to get back in here and give an update after some experience with these big bits. I has powered through 3/4" cuts easily (even when I tried to hog too much)
Plunge: Smooth as silk!
Speed control: Having it on the handle is really, really nice. It is right under your right thumb. I use it for every startup and shutdown. It gives you a reall feel of control.
Table mount: Mounted easily, and height control is easy with the standard height adjustment knob.
Low Points:
Size: This thing is BIG and heavy. You will probably want to have a smaller router as well to complement this router.
Collet: So far I have been having trouble getting bits into and out of the collet. Hopefully this will wear in and get easier. I will try to do an update after a couple of months.
Overall I am thrilled.
Patrick Robinson
Washington Woodworker
Update: I have had this router for 6 months now and still love it. The collet has loosened up nicely and bits come out easily. You need to make sure that the collet is snapped together when you put the bits in place, or they will be hard to remove. It has a ton of power. I have been driving large bits and it just plows through hard woods. It works great in my router table!

I was looking for a large, powerful router for woodworking to replace an old router I own. This one has performed beyond my expectations. It is much larger in size than I imagined, but all the controls, clamps, adjustments, etc. were thought out and executed so well, that its size hasn't been an issue at all.
